Support Motherboard Type

Mini-ITX

(170mm x 170mm)

Mini-ITX

(170mm x 170mm)

Mini-ITX

(170mm x 170mm)

ATX (305mm x 244mm)

I/O Interface

USB

4    (Not Contain M/B Rear  IO  with USB Port)

Come from the M/B Rear IO

4    (Not Contain M/B Rear  IO  with USB Port)

LPT

1    (Decided by the M/B)

1    (Decided by the M/B)

1    (Decided by the M/B)

COM

6    (Not Contain M/B Rear

   IO   COM Port )

2    (Not Contain M/B Rear

   IO   COM Port )

Up to 14

(Decided by the M/B)

PS/2

Yes (Decided by the M/B)

Come from the M/B Rear IO

Come from the M/B Rear IO

Display Port

Decided by the M/B

Come from the M/B Rear IO

Come from the M/B Rear IO

PCI or PCIe Slot

1 (Decided by the M/B)

2

7

Front Panel

1 x Power Button

1 x Power Button

1 x Power Button

1 x Power LED

1 x Power LED

1 x Power LED

1 x HDD   LED

1 x HDD   LED

1 x HDD   LED

1 x Reset Button

1 x Reset Button

N/A

Cooling

FAN

2 (225px/2800RPM)

2 (225px/2800RPM)

2 (200px/3200RPM)

Air Filter

Yes

Yes

Yes

Environment

Temperature

-20~70℃

-20~70℃

-20~70℃

Humidity

5 ~ 90%, non-condensing

5 ~ 90%, non-condensing

5 ~ 90%, non-condensing

Mechanical

Structure

Dimensions (WxHxD)

293mm x 241mm x 153mm

320mm x 261mm x 156mm

323mm x 310mm x 175mm

Material

SECC 1.2

SECC 1.2

SGCC 1.2

Mouting

Wall-Mount

Wall-Mount

Wall-Mount

Disk Driver Bay

HDD

1 x 3.5" / 1   x 2.5"

1 x 3.5"

1 x 3.5"

Optical Driver

N/A

N/A

N/A

Power Supply

Flex-ATX Power

(Optional Power)

ATX Power

(Optional Power)

ATX Power

(Optional Power)
