Frequency

2.24GHz (4C/4T)

TDP

Up to 6W

BIOS

AMI UEFI

DRAM

Technology

DDR3L 1600MHz

Capacity

4GB

Socket

On-board (Dual Channel)

Display

Graphics

Within Braswell SoC Support DX11.1 & OpenCL 1.2

Graphics Memory

Share System memory up to 1.7GB SDRAM

VGA

1 (Pin-Header)

DVI-D

1

LVDS

24bit Dual Channel

Multiple Display

Two or Three Independent displays

LAN

2*intel LAN (i211-AT+ i210-AT)

Audio

Realtek ALC887 with Line-in/MIC/Line-out

Watchdog

1~255 Watchdog Times

Storage

SATA

1 x SATA3.0 (6Gb/s)

mSATA

1 (Full-Size)

I/O

COM Port

6 x RS232 (COM1&COM2 Support RS232/422/485,
  COM1 Support 5V/12V Power)

USB

4 x USB3.0 + 3 x USB2.0

GPIO

8 x In , 8-Out

PS/2

1

Expansion
  Slot

PCI104

1

SIM

1

Mini PCIe

1

Power

DC-In

DC 12V In

DC-Out

Support 5V/12V Out for 2.5”or 3.5”HDD

Form Factor

165mm x 115mm (EPIC)

Environment

Operation Temp
  & Humidity

-10~70℃
  /10~90%,non-condensing

Storage Temp
  & Humidity

-20~80℃
  /10~90%,non-condensing

Certification

EMC

CE / FCC

O.S

Windows 10 64Bit/Windows 7 32/64-Bit (Pro/WES7/WE POSready7) / Windows 8.1 64-Bit /Linux Kernel 3.14+
